#define ACC_MODE(x) ("\004\002\006\377"[(x)&O_ACCMODE])/* * comment out this line if you want names > NAME_LEN chars to be * truncated. Else they will be disallowed. *//* #define NO_TRUNCATE */#define MAY_EXEC 1#define MAY_WRITE 2#define MAY_READ 4/* *	permission() * * is used to check for read/write/execute permissions on a file. * I don't know if we should look at just the euid or both euid and * uid, but that should be easily changed. */// 判断有没有mask指定的权限static int permission(struct m_inode * inode,int mask){   	int mode = inode->i_mode;/* special case: not even root can read/write a deleted file */	if (inode->i_dev && !inode->i_nlinks) // 没有被引用		return 0;	else if (current->euid==inode->i_uid) // 是文件的属主则取判断属主的权限		mode >>= 6;	else if (current->egid==inode->i_gid) // 判断组属性		mode >>= 3;	if (((mode & mask & 0007) == mask) || suser()) // 否则判断other的属性，是超级用户则肯定有权限		return 1;	return 0;}/* * ok, we cannot use strncmp, as the name is not in our data space. * Thus we'll have to use match. No big problem. Match also makes * some sanity tests. * * NOTE! unlike strncmp, match returns 1 for success, 0 for failure. */static int match(int len,const char * name,struct dir_entry * de){   	register int same __asm__("ax"); 	if (!de || !de->inode || len > NAME_LEN)		return 0;	if (len < NAME_LEN && de->name[len])		return 0;	__asm__("cld\n\t"		"fs ; repe ; cmpsb\n\t"		"setz %%al"		:"=a" (same)		:"0" (0),"S" ((long) name),"D" ((long) de->name),"c" (len)		:"cx","di","si");	return same;}/* *	find_entry() * * finds an entry in the specified directory with the wanted name. It * returns the cache buffer in which the entry was found, and the entry * itself (as a parameter - res_dir). It does NOT read the inode of the * entry - you'll have to do that yourself if you want to. * * This also takes care of the few special cases due to '..'-traversal * over a pseudo-ro	ot and a mount point. */// 在dir目录项中找到名称等于name的目录项，存放到res_dir中static struct buffer_head * find_entry(struct m_inode ** dir,	const char * name, int namelen, struct dir_entry ** res_dir){   	int entries;	int block,i;	struct buffer_head * bh;	struct dir_entry * de;	struct super_block * sb;#ifdef NO_TRUNCATE	if (namelen > NAME_LEN)		return NULL;#else	if (namelen > NAME_LEN)		namelen = NAME_LEN;#endif	// 当前节点（目录）的大小除以每个目录项的大小，得出目录项的数量	entries = (*dir)->i_size / (sizeof (struct dir_entry));// 该目录下的目录项总数	*res_dir = NULL;	if (!namelen)		return NULL;/* check for '..', as we might have to do some "magic" for it */	// 形如../a/b，当前的目录名是..	if (namelen==2 && get_fs_byte(name)=='.' && get_fs_byte(name+1)=='.') {   /* '..' in a pseudo-root results in a faked '.' (just change namelen) */		// 当前目录是..并且当前所在的目录是根节点则重写namelen等于1即当前目录，因为无法再回退		if ((*dir) == current->root)			namelen=1;		/*  如果inode在硬盘中的节点号是1说明是文件系统的根节点，			这时候不是回退到该根节点的上级，而是从挂载的文件系统的根节点开始找		*/		else if ((*dir)->i_num == ROOT_INO) {   /* '..' over a mount-point results in 'dir' being exchanged for the mounted   directory-inode. NOTE! We set mounted, so that we can iput the new dir */			// 取出该inode对应的超级块			sb=get_super((*dir)->i_dev);			// 判断该超级块是否挂载在某inode上，是的话重新赋值查找的起点inode			if (sb->s_imount) {   				iput(*dir);				(*dir)=sb->s_imount;				(*dir)->i_count++;			}		}	}	// 取出该目录在硬盘中对应的第一块数据块，然后读进来	if (!(block = (*dir)->i_zone[0]))		return NULL;	if (!(bh = bread((*dir)->i_dev,block)))		return NULL;	i = 0;	// 指向第一个目录项	de = (struct dir_entry *) bh->b_data;	// entries为总目录项，等于很多块的目录项组成，遍历所有的目录项	while (i < entries) {   		// 读完目录对应inode节点中的第一块数据，没找到，继续读下一块的目录项数据		if ((char *)de >= BLOCK_SIZE+bh->b_data) {   			brelse(bh);			bh = NULL;			// 算出i/DIR_ENTRIES_PER_BLOCK，即得到属于7+512+512*512个块中的哪一块，然后得到当前目录项对应硬盘里的块数，然后读进来			if (!(block = bmap(*dir,i/DIR_ENTRIES_PER_BLOCK)) ||			    !(bh = bread((*dir)->i_dev,block))) {   				// 读取失败则跳过该数据块，i+DIR_ENTRIES_PER_BLOCK表示继续读取下一块数据块				i += DIR_ENTRIES_PER_BLOCK;				continue;			}			// 指向新的数据块中的第一个目录项			de = (struct dir_entry *) bh->b_data;		}		// 遍历每个目录项，比较名字是否相等，是的话说明找到了，每个目录项里都存着..和.对应的项		if (match(namelen,name,de)) {   			*res_dir = de;			return bh;		}		// 没找到指向下一个目录项		de++;		// 累计已经遍历的项数		i++;	}	brelse(bh);	return NULL;}/* *	add_entry() * * adds a file entry to the specified directory, using the same * semantics as find_entry(). It returns NULL if it failed. * * NOTE!! The inode part of 'de' is left at 0 - which means you * may not sleep between calling this and putting something into * the entry, as someone else might have used it while you slept. */// 新增一个目录项static struct buffer_head * add_entry(struct m_inode * dir,	const char * name, int namelen, struct dir_entry ** res_dir){   	int block,i;	struct buffer_head * bh;	struct dir_entry * de;	*res_dir = NULL;#ifdef NO_TRUNCATE	if (namelen > NAME_LEN)		return NULL;#else	if (namelen > NAME_LEN)		namelen = NAME_LEN;#endif	if (!namelen)		return NULL;	if (!(block = dir->i_zone[0]))		return NULL;	if (!(bh = bread(dir->i_dev,block)))		return NULL;	i = 0;	// 该目录在硬盘中的第一块数据块	de = (struct dir_entry *) bh->b_data;	while (1) {   		// 如果当前块已经查找完毕，读入下一块，如果没有下一块则创建一个		if ((char *)de >= BLOCK_SIZE+bh->b_data) {   			brelse(bh);			bh = NULL;			block = create_block(dir,i/DIR_ENTRIES_PER_BLOCK);			if (!block)				return NULL;			// 读取失败则跳过			if (!(bh = bread(dir->i_dev,block))) {   				i += DIR_ENTRIES_PER_BLOCK;				continue;			}			de = (struct dir_entry *) bh->b_data;		}		// 找到了全部块的末尾，即找到了追加entry的位置，更新大小等属性		if (i*sizeof(struct dir_entry) >= dir->i_size) {   			de->inode=0;			dir->i_size = (i+1)*sizeof(struct dir_entry);			dir->i_dirt = 1;			dir->i_ctime = CURRENT_TIME;		}		// 在每一块中找第一项还没使用的目录项		if (!de->inode) {   			dir->i_mtime = CURRENT_TIME;			for (i=0; i < NAME_LEN ; i++)				de->name[i]=(i

    b_dirt = 1;			*res_dir = de;			return bh;		}		de++;		i++;	}	brelse(bh);	return NULL;}/* *	get_dir() * * Getdir traverses the pathname until it hits the topmost directory. * It returns NULL on failure. */// 找出给定路径最后一级目录的inode节点static struct m_inode * get_dir(const char * pathname){   	char c;	const char * thisname;	struct m_inode * inode;	struct buffer_head * bh;	int namelen,inr,idev;	struct dir_entry * de;	if (!current->root || !current->root->i_count)		panic("No root inode");	if (!current->pwd || !current->pwd->i_count)		panic("No cwd inode");	// 路径名以/开头说明是绝对路径，则搜索节点是该进程的根节点，否则是当前工作路径	if ((c=get_fs_byte(pathname))=='/') {   		inode = current->root;		pathname++;	} else if (c)		inode = current->pwd;	else		return NULL;	/* empty name is bad */	inode->i_count++;	// 逐个目录查找	while (1) {   		thisname = pathname;		// 不是目录或者没有执行的权限		if (!S_ISDIR(inode->i_mode) || !permission(inode,MAY_EXEC)) {   			iput(inode);			return NULL;		}		// 获取某一级目录名		for(namelen=0;(c=get_fs_byte(pathname++))&&(c!='/');namelen++)			/* nothing */ ;		// 跑到这里说明c是null或者c等于/，如果是空说明查找完毕，直接返回，否则根据目录名找到对应的目录项内容		if (!c)			return inode;		// 在inode节点下查找，thisname为当前级的目录名，namelen为当前级目录名长度		if (!(bh = find_entry(&inode,thisname,namelen,&de))) {   			iput(inode);			return NULL;		}		// 找到当前目录对应的dir_entry结构，		inr = de->inode;		idev = inode->i_dev;		brelse(bh);		iput(inode);		// 取出设备中inode号为inr的目录项数据		if (!(inode = iget(idev,inr)))			return NULL;	}}/* *	dir_namei() * * dir_namei() returns the inode of the directory of the * specified name, and the name within that directory. */// 找出路径的最后一级目录的inode和路径中的文件名static struct m_inode * dir_namei(const char * pathname,	int * namelen, const char ** name){   	char c;	const char * basename;	struct m_inode * dir;	if (!(dir = get_dir(pathname)))		return NULL;	// 初始化值等于pathname，比如传入的是1.txt	basename = pathname;	// 取路径中最后一个/的剩余部分作为文件名	while (c=get_fs_byte(pathname++))		if (c=='/')			basename=pathname;	*namelen = pathname-basename-1;	*name = basename;	return dir;}/* *	namei() * * is used by most simple commands to get the inode of a specified name. * Open, link etc use their own routines, but this is enough for things * like 'chmod' etc. */// 根据路径找到文件的inode节点struct m_inode * namei(const char * pathname){   	const char * basename;	int inr,dev,namelen;	struct m_inode * dir;	struct buffer_head * bh;	struct dir_entry * de;	// 找到pathname最后一级目录的inode和解析出路径中的文件名	if (!(dir = dir_namei(pathname,&namelen,&basename)))		return NULL;	if (!namelen)			/* special case: '/usr/' etc */		return dir;	// 在最后一级目录中查找basename的文件名的目录项，存在de中	bh = find_entry(&dir,basename,namelen,&de);	if (!bh) {   		iput(dir);		return NULL;	}	inr = de->inode;	dev = dir->i_dev;	brelse(bh);	iput(dir);	// 读取设备dev中inode节点号为inr的inode结构	dir=iget(dev,inr);	if (dir) {   		dir->i_atime=CURRENT_TIME;		dir->i_dirt=1;	}	return dir;}/* *	open_namei() * * namei for open - this is in fact almost the whole open-routine. */int open_namei(const char * pathname, int flag, int mode,	struct m_inode ** res_inode){   	const char * basename;	int inr,dev,namelen;	struct m_inode * dir, *inode;	struct buffer_head * bh;	struct dir_entry * de;	// 设置了trunc但没有设置读写标记位则设置成只写	if ((flag & O_TRUNC) && !(flag & O_ACCMODE))		flag |= O_WRONLY;	mode &= 0777 & ~current->umask;	mode |= I_REGULAR;	// 根据pathname找出最后一级目录的inode节点，并返回文件名和长度	if (!(dir = dir_namei(pathname,&namelen,&basename)))		return -ENOENT;	// 文件名长度是0说明最后一级是目录	if (!namelen) {   			/* special case: '/usr/' etc */		if (!(flag & (O_ACCMODE|O_CREAT|O_TRUNC))) {   			*res_inode=dir;			return 0;		}		iput(dir);		return -EISDIR;	}	// 从最后一级目录的目录项中查找等于basename的目录项，存储到de中	bh = find_entry(&dir,basename,namelen,&de);	if (!bh) {   		if (!(flag & O_CREAT)) {   			iput(dir);			return -ENOENT;		}		if (!permission(dir,MAY_WRITE)) {   			iput(dir);			return -EACCES;		}		inode = new_inode(dir->i_dev);		if (!inode) {   			iput(dir);			return -ENOSPC;		}		inode->i_uid = current->euid;		inode->i_mode = mode;		inode->i_dirt = 1;		bh = add_entry(dir,basename,namelen,&de);		if (!bh) {   			inode->i_nlinks--;			iput(inode);			iput(dir);			return -ENOSPC;		}		// 保存新建的inode节点的节点号		de->inode = inode->i_num;		bh->b_dirt = 1;		brelse(bh);		iput(dir);		*res_inode = inode;		return 0;	}	inr = de->inode;	dev = dir->i_dev;	brelse(bh);	iput(dir);	// O_EXCL表示该文件必须是由当前进程创建	if (flag & O_EXCL)		return -EEXIST;	// 获取文件内容	if (!(inode=iget(dev,inr)))		return -EACCES;	if ((S_ISDIR(inode->i_mode) && (flag & O_ACCMODE)) ||	    !permission(inode,ACC_MODE(flag))) {   		iput(inode);		return -EPERM;	}	inode->i_atime = CURRENT_TIME;	if (flag & O_TRUNC)		truncate(inode);	*res_inode = inode;	return 0;}
